 Home >>Temperature and Pressure Switches >>Industrial Pressure Switches>>FP Ultra Low Series
FP Ultra Low   Orion FP Ultra Low Series Pressure Switches have been designed for low pressure (2 mmWC) applications that require robust, long lasting switches, coupled with high accuracy and repeatability.
  •       SUMMARY
  •      SPECIFICATIONS
  •       ORDER CODE
  •          PRICE
  •     DOWNLOADS
• Ultra Low range (2 mmSS) Pressure and Differential,
• Cast aluminum robust case,
• Reliable and sensitive microswitch,
• 10.000.00 on-off microswitch lifetime,
• IP66 protection class,
• 1% accuracy,
• Easy and safe wiring,
• Direct or panel mounting, for outside and inside area,,
• Tested and proven reliability.





 Range 2 mmSS to 40 mbar- Differential pressure
 Measurement element Diaphragm; Silicone
 Switch SPDT Snap action switch, Max.1 A / 250 VAC
 Differential type Fix
 Protection class IP66
 Body Cast aluminum
 Max.Temperature 80 oC
 Cable input 1/2" NPT
 Repeatability 1% of F.S.
 Pressure connection 1/8" BSP thread x 2
 Pressure connection material Aluminum
 Mounting Direct or panel mounting, for outside and inside area,

     ORDER CODE

This chapter is for our members use only.

If you are a member click here,
If you are not a member, to register for click here
