 Home >>Temperature and Pressure Switches >>OEM>>MZ Series
MZ Series   Orion MZ Series OEM Pressure Switches are housed in a tough polycarbonate IP 66 enclosure and are intended for outdoor use. The repeat accuracy is better than 2 % FS a choice of cable entries can be fitted to the enclosure.
  •       SUMMARY
  •      SPECIFICATIONS
  •       ORDER CODE
  •          PRICE
  •     DOWNLOADS
• Reasonable price,
• Transparent polycarbonate housing,
• Reliable and sensitive microswitch,
• IP66 protection class,
• Easy and safe wiring,
• Direct or panel mounting, for outside and inside area,,
• OEM production opportunities.





 Range 0.1 Bar to 25 bar
 Measurement element Diaphragm; Neoprene, Teflon, Reinforced plastic
 Switch SPDT Snap action switch, Max.15 A / 250 VAC
 Differential type Fix or Adjustable
 Protection class IP66
 Body Transparent polycarbonate housing
 Max.Temperature 80 oC
 Cable input M20x1.5 Gland
 Repeatability 1%, 2% of F.S.
 Pressure connection 1/4" NPT thread
 Pressure connection material AISI 316 SS
 Mounting Direct or panel mounting, for outside and inside area,

     ORDER CODE


This chapter is for our members use only.

If you are a member click here,
If you are not a member, to register for click here
