 Home >>Temperature and Pressure Switches >>Compact Pressure Switches>>P Series
P Series   Orion P Series pressure difference switches are housed in pressure die cast aluminium powder coated enclosure and are recommended for panel mounting or outdoor service based on the type of enclosure opted for.
  •       SUMMARY
  •      SPECIFICATIONS
  •       ORDER CODE
  •          PRICE
  •     DOWNLOADS
• Ready to use, easy assembly, easy adjustability,
• Option; suitable material on operating conditions.,
• Cast aluminum case, robust,
• PTFE and AISI 316 SS diaphragm,
• Low pressure control (15 mBar),
• IP65 protection class,
• Adjustable in the field.






 Range 10 mBar to 3.6 bar Differential Pressure
 Measurement element Diaphragm; Neoprene, Teflon, Reinforced plastic
 Switch SPDT Snap action switch, Max. 5 A / 250 VAC, 0.2 A, 250VDC
 Differential type Fix or Adjustable
 Protection class IP54, IP65
 Body Cast aluminum
 Max.Temperature 80 oC
 Cable input 3/8" NPT Gland
 Repeatability 2% of F.S.
 Pressure connection 1/4" NPT or BSP thread
 Pressure connection material Aluminum, Brass and AISI 316 SS
 Mounting Direct or panel mounting, for outside and inside area,
